DAWNCAP DMS Series 0.035µF 20kV Ultra-High Voltage Power Film Capacitor

**DAWNCAP DMS Series 0.035µF 20kV Polypropylene Film Capacitor**

Industrial-grade high-voltage capacitor engineered for pulse discharge, resonant power transfer, and high-frequency energy systems. Built with durable polypropylene film dielectric and optimized for long-term reliability under extreme conditions.

**⚙️ Features**
• Ultra-high voltage rating up to 20,000 VDC
• Precision 0.035 µF (35,000 pF) capacitance
• Polypropylene film dielectric for low loss and high stability
• Compact cylindrical design with heavy-duty terminals
• Excellent insulation resistance and low dissipation factor
• Suitable for pulse, resonance, and energy transfer circuits
• Reinforced epoxy sealing for moisture and temperature resistance

**📦 Specifications**
• Model: DMS 0.035 µF 20000 VDC
• Capacitance: 0.035 µF (35,000 pF)
• Rated voltage: 20 kV DC
• Dielectric: Polypropylene film
• Package type: Surface mount / screw terminal
• Operating temperature: -40 °C to +85 °C
• Structure: Fixed film capacitor
• Color: White
• Brand: DAWNCAP

**🧰 Applications**
• High-voltage power supplies and inverter systems
• Resonant and pulse discharge circuits
• Induction heating and RF energy systems
• Tesla coil and experimental resonant devices
• Research, laboratory, and educational high-voltage setups

**🧩 Notes**
• Use in properly insulated high-voltage environments.
• Avoid mechanical stress and overvoltage operation.
• Allow sufficient cooling during pulse or resonant use.
